| 頻率 / Frequency: | UHF640-690MHz |
| 調制 / Modulation: | FM |
| 信道 / Channel: | 2Channel, 200 frequency/雙信道，200頻點 |
| 頻率間隔 / Frequency interval: | 250KHz |
| 穩定度 / Stability: | ±0.005% |
| 動態范圍 / Dynamic range: | 100dB |
| 調制度 / Modulation: | ±55KHz |
| 頻率響應 / Response: | 30Hz~18KHz (±3dB) |
| 信噪比 / S/N ratio: | <105dB |
| 失真度 / THD: | ≤0.5% |
| 工作距離 / Working range: | About 150M (Without obstacle) |
| 中頻 / Intermediate frequency: | 110MHz, 10.7MHz |
| 天線接入 / Antenna switch in:: | TNC / 50Ω |
| 靈敏度 / Sensitivity: | 12-32dB |
| 最大電平 / Max output: | ±10dB/V |
| 供電電壓 / Power voltage: | DC12-15V |
| 電流 / Current: | >320MA |
| 靜噪門 / Squelch Level: | 0-40dB(1.5V)5kΩ |
