| 頻率范圍 / Frequency Range: | 610-680MHz |
| 調制方式 / Modulation mode: | FM |
| 通道 / Number of Channels: | Single Channel |
| 頻率響應 / Frequency Response: | 60Hz-13kHz |
| 最大頻率偏差 / Max.Frequency Deviation: | ±15kHz |
| 頻率穩定性 / Frequency Steadiness: | ±0.005% |
| 信噪比 / S/N ratio: | >70dB |
| 總諧波失真 / Total Harmonic Distortion: | ≤ 0.5%（at 1kHz） |
| 發射功率 / Transmit Power: | ≤ 10mW |
| 接收器電源 / Receiver Power Supply: | DC 9V/300mA，External |
| 發射機電源 / Transmitter Power Supply: | 9V Tier Battery |
| 輸出類型 / Output Type: | Separate or Mixed Output |
| 音頻動態范圍 / Audio Dynamic Range: | Over 100dB，Over 118dB with limiting |
| 服務范圍 / Service Areas: | 50 meters |
| 溫度范圍 / Temperature Range: | -20”C to 50′C |
